Description Of Machine
This light pole polishing machine steel tube adopt self-run and the movement of the machine in order to move the steel tube. The machine is fitted with grinding polishing bar, these grinding polishing bars will grind and polish the surface of steel tube quickly. It is speedy, efficient, saving workers and energy. It was the first choice for grinding and polishing every pole.
Parameters
| No. | Model | Value | Unit | |
| 1 | Diameter of grinding steel tube | Ø350 | MM | |
| 2 | Length of grinding steel tube | 12000 | MM | |
| 3 | Steel tube run around speed | 5-10 | Turn/M | |
| 4 | Grinding steel tube run speed | 1100 | MM/M | |
| 5 | Measure | L | 13000 | MM |
| W | 2000 | MM | ||
| H | 800 | MM | ||
| 6 | Weight | 1500 | KG | |
Spare Parts Supplier
| SN | Name | Spec. | Qty | Supplier |
| 1 | Sand belt motor | 4 KW | 1set | Siemens Beide |
| 2 | Walking adjustable motor | 0.75KW | 1set | Siemens Beide |
| 3 | Rotating motor | 0.55 KW | 1set | Siemens Beide |
| 4 | Dustless Motor | 3 KW | 1set | Shanghai |
| 5 | Electric components | 1set | Schneider | |
| 6 | Reducer | Bwd150 | 1set | Dajiang |
| 7 | Rotating reducer | Bwd150 | 1set | Dajiang |
